RCD/RCCB/RCBO：HCL7-63 Residual Current Circuit Breaker　[Hits：624]　
HCL7-63 Residual Current Circuit Breaker

Specification and Feature

■ High-quality residual current device/miniature circuit breaker combination, line
     voltage-independent
■ Contact position indicator red-green
■ Colour code for rated tripping currents
■ Comprehensive range of accessories suitable for subsequent installation
■ Wide variety of rated tripping currents
■ Rated currents up to 40A
■ Tripping characteristics C
■ Rated breaking capacity 10KA

Technical Data

In/i△n/(A)
 Type Designation
 Article No
 Units per package
2/0.03
 HCL7-2/1N/C/003
 382153
 1/60
4/0.03
 HCL7-4/1N/C/003
 382154
 1/60
6/0.03
 HCL7-6/1N/C/003
 382155
 1/60
10/0.03
 HCL7-10/1N/C/003
 382156
 1/60
15/0.03
 HCL7-15/1N/C/003
 382157
 1/60
16/0.03
 HCL7-16/1N/C/003
 382158
 1/60
20/0.03
 HCL7-20/1N/C/003
 382159
 1/60
25/0.03
 HCL7-25/1N/C/003
 382160
 1/60
32/0.03
 HCL7-32/1N/C/003
 382161
 1/60
40/0.03
 HCL7-40/1N/C/003
 382162
 1/60
2/0.1
 HCL7-2/1N/C/01
 382163
 1/60
4/0.1
 HCL7-4/1N/C/01
 382164
 1/60
6/0.1
 HCL7-6/1N/C/01
 382165
 1/60
10/0.1
 HCL7-10/1N/C/01
 382166
 1/60
15/0.1
 HCL7-15/1N/C/01
 382167
 1/60
16/0.1
 HCL7-16/1N/C/01
 382168
 1/60
20/0.1
 HCL7-20/1N/C/01
 382169
 1/60
25/0.1
 HCL7-25/1N/C/01
 382170
 1/60
32/0.1
 HCL7-32/1N/C/01
 382171
 1/60
40/0.1
 HCL7-40/1N/C/01
 382172
 1/60
